Brand Name : | DWIN |
Model Number : | DW1530 |
Certification : | CE FDA SGS |
Price : | 14500-19000usd |
Payment Terms : | L/C, T/T, Western Union |
Supply Ability : | 200 sets / month |
Delivery Time : | 10-20 working days |
Model | Affordable Metal Tube Laser Cutting Machine DW1530 |
Laser Power | 1000W/1500W/2000W/3000W/4000W/ |
Pipe Processing Range | 6000mm* φ10~220mm (Square tube: 10*10~150*150mm) |
Maximum Speed | 100m/min |
Maximum Rotational Speed | 100r/min |
Z-axis Travel | 170mm |
Positioning Accuracy | ±0.05mm |
Repeated Positioning | ±0.02mm |
Maximum Acceleration | 0.8G |
Table Maximum Load(KG) | 700 |
Outline Size(mm) | 9000*2900 *2400 |
Power Parameters | Three-phase AC 380V 50Hz |
Protection Level of Total Power Supply | IP54 |
