CNC multi spindle drill head tube plate drilling and milling
machine for metal sieve plate
1.High temperature tempering treatment, welded steel tube machine
bed and gantry, high rigidity, bearing strength better.
2.High accuracy ball screw imported from Germany assure machine
frame with the high precision.
3.Break point and break bits continue engraving function can
support up to nine points and can engrave at any places as you
like.
4.Linear square guide rail with automatic oil lubrication device,
ensuring long life time working, reduce the time of machine
maintenance.
5.mainly used for drilling and milling plate type workpiece which
in buildings, bridges, towers and other steel structure industry,
and also can process tube plate,baffle plate and circular flange of
boiler and petrochemical industry.It can drill through-hole,
blind-hole, ladder hole, hole-end chamfering and milling,etc
Technical parameter:
| Model | DW1325 |
| Working area | 1300x2500mm |
| Machine color | As customer request |
| Spindle power | 2.2kw-9kw can option |
| Cooling mode | Water cooling or air cooling |
| control system | NC-studio/DSP/MACH3 option |
| spindle rptating speed | 0-24000rpm/min |
| Max travel speed | 8000mm/min |
| Power supply | 220V / 380V, Signal /three phase |
| Graphic format supported | BMP, PLT, DST, DXF, AI,CDR,GIF,DWG |
| Software supported | CorelDraw, Photo Shop, AutoCAD |
| command | G code*.u00*.mmg*.plt |
| Resolution ratio | <0.01mm |
| Location precision | <0.01mm |
| Working temperature/ Operating humidity | 5°C-40°C/ 5%-95%(without condensed water) |
| Net Weight | 1200KG |
| Option parts | vacuum table,servo motor,etc. |
| Machine warranty | 24 months |
| Tool box | Including |
Samples
Package
1) Whole film packaging machine.
2) Anti-collision package edge.
3) Fumigation-free plywood wooden box with an iron-binding belt.
