    20mm Acrylic Co2 Laser Cutting And Engraving Machine 1300x900mm

    Ask Lasest Price
    Brand Name : DWIN
    Model Number : DW1390
    Certification : CE FDA SGS
    Price : 3000-4000usd
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 200 sets / month
    Delivery Time : 8-10 working days
    • Product Details
    • Company Profile

    20mm Acrylic Co2 Laser Cutting And Engraving Machine 1300x900mm

    1300x900mm 20mm acrylic co2 laser cutting and engraving machine

    1 . Co2 Laser Cutting And Engraving Machine With new generation belt mold, more thick and wide, which is more high accurate and more longer life.
    2 . Laser tube is separated with the working table, this make sure laser tube safety and laser path clean.
    3 . Many labels and remarks in the machine, very useful for the beginner. and more safe for new users.
    4 . Use China best leadshine stepper motor, which make sure get more high precision.
    5 . Support USB port transmit data, have DSP offline function, improving working speed and efficiency greatly.

    6 . Co2 Laser Cutting And Engraving Machine with 24 months warranty , if wrong in warranty , can change new one for you by free

    7 . Blade and honeycomb double table will not have any problem no matther customer cutting or engraving materials .

    8 . With Machine full tools box , so when machine arrive customers ,can install the machine very easy

    9 . Using Chinese best laser tube Reci laser tube and best chiller S&A brand .

    10 . Machine pack all wood box , so that during shipping by sea or air , will not have damage .


    Technical parameter:


    ModelDW1390 Co2 Laser Cutting And Engraving Machine
    Working area1300x900mm
    Machine colorAs customer request
    Laser typeCO2 laser tube
    Cooling modeWater cooling (S&A CW5000 Chiller)
    Laser powerW6Reci laser tube ( 130w-160w )
    Cutting speed0-10000mm/min

    Minimum shaping character

    Letter 1mm, Chinese 2mm
    Power supply220V / 110V, Signal phase
    Graphic format supported

    BMP, PLT, DST, DXF, AI,CDR,GIF,DWG

    Software supported

    CorelDraw, Photo Shop, AutoCAD

    Laser Output Control1-100% software setting
    Highest Scanning Precision2500DPI
    Resolution ratio<0.01mm
    Location precision<0.01mm
    Working temperature/ Operating humidity5°C-40°C/ 5%-95%(without condensed water)
    Net Weight450KG
    Option partsUp-down worktable, Auto focus, Rotary device.
    Machine warranty24 months

    Tool box

    Including

    Samples
